4K HD 12X 3840X2160 Wide Angle Recording PTZ Cameras - UHV-400H Winsafe
UHV-400H is a professional grade UHD video camera, video streaming from IP, HDMI,3G-SDI&USB3.0 simultaneously, very ideal for Lecture Capture and Event Recording in classroom.
Advantages
※ Adopts most advanced DSP,1/2.5 inch 12MP sensor
※ 4K wide angle optical lens: 12x optical zoom, 72.5° field of view
※ 4K video over IP, and support H.264, H.265 encoding
※ Support POE: easy to use one RJ45 cable to get video, control and power supply
※ IP,HDMI,SDI,USB outputs, fit for different application
※ Special Focusing Algorithm: fast and precise focusing performance when zooming or moving
※ Standard Sony Visca, Pelco-P, Pelco-D control protocol
※ Supplied with function IR remote controller, can set IP address via OSD menu
Features
※ IP, HDMI,SDI and USB outputs simultaneously
※ 12X optical zoom + 2X digital zoom
※ 3840x2160p30 Ultra HD video resolution
※ Automatic access to the IP address
※ Smooth PTZ mechanical design, accurate pan tilt motor control
※ WDR, 3D Noise Reduction feature
※ 128 presets
※ Support RS232/RS485 serial control
※ Image flip function, support upside-down installation
※ Sony Visca and Pelco D/P protocol
※ Support daisy chain feature
3840X2160P30 ULTRA HD VIDEO RESOLUTION
12X OPTICAL ZOOM + 2X DIGITAL ZOOM, 72.5 DEGREE FIELD OF VIEW
IP, 3G-SDI, HDMI AND USB 3.0 VIDEO OUTPUT SIMULTANEOUSLY
POE SUPPORTED
UHV-400H is a professional grade UHD video camera, video streaming from IP, HDMI,3G-SDI&USB3.0 simultaneously, very ideal for Lecture Capture and Event Recording in classroom.
Specification
|
Model No. |
UHV-400-H |
|||
|
Sensor |
1/2.5" 12Megapixel high quality CMOS Sensor |
|||
|
Video System |
HDMI |
IP |
SDI |
USB3.0 |
|
3840x2160p30/25 |
Main Steam: |
1080p60/50/30/25 |
1080p60/50/30/25 |
|
|
Zoom |
12x optical zoom + 2x digital zoom |
|||
|
FOV |
6.3°(near) - 72.5°(far) |
|||
|
F.no. |
Wide: 1.84 Tele: 2.81 |
|||
|
Min.Focus Distance |
Wide: 0.3m Tele:1m |
|||
|
Preset |
10 via remote controller; 128 via serial port; preset precision: 0.1° |
|||
|
Pan Rotation Angle |
- 170° - +170° |
|||
|
Tilt Roation Angle |
- 35° - + 90° |
|||
|
Pan Rotation Speed |
0° - 120° /s |
|||
|
Tilt Rotation Speed |
0° - 80° /s |
|||
|
Control Port |
RS232/RS485/RJ45 |
|||
|
Video Port |
HDMI/RJ45/SDI/USB3.0/USB2.0 |
|||
|
Network Speed |
1000M |
|||
|
Noise Reduction |
2D & 3D |
|||
|
SNR |
Above 50dB |
|||
|
Focal Length |
f=3.92(near) - 47.32mm(far) |
|||
|
Minimum Lux |
0.01Lux |
|||
|
White Balance |
Auto/Manual/Auto Tracking/OnePush/Indoor/Outdoor |
|||
|
Anti Flicker |
50Hz/60Hz/OFF |
|||
|
D/N Mode |
Supported |
|||
|
Gamma |
Supported |
|||
|
Mirror Image |
Supported |
|||
|
PanTilt Flip |
Supported |
|||
|
Iris |
Auto/Manual |
|||
|
Electric Shutter |
Auto/Manual |
|||
|
BLC |
Auto/Manual |
|||
|
Focus |
Auto/Manual |
|||
|
Video Encoding |
H.264/H.265 |
|||
|
Bit Rate Control |
Variable Bit Rate, Constant Bit Rate |
|||
|
Video Bit Rate |
1024Kbps - 30720Kbps |
|||
|
Frames |
50HZ: 1fps - 50fps; 60HZ: 1fps - 60fps (3840 x 2160 max.30fps) |
|||
|
IP Protocol |
TCP/IP, HTTP,RTSP, RTMP, Onvif, DHCP |
|||
|
POE |
Supported |
|||
|
Input Voltage |
DC12V, 2A |
|||
|
Dimension |
220mm x 173mm x 190mm |
|||
|
Net Weight |
1.25KGS(2.8LBS) |
|||
