Description
The Aruba Instant On 1830 JL811A 8-Port Gigabit PoE+ Compliant Managed Network Switch helps to quickly grow your small business's network capacity to keep up with the growing list of power over Ethernet devices such as IP security cameras, access points, and VoIP phones. This entry-level managed rackmount switch includes eight Gigabit Ethernet ports, four of which are PoE+ compliant with a 65W power budget. It also supports a host of Layer 2 features without any additional licensing fees. Use the Aruba Instant On mobile app, cloud-based web portal, or local web interface to quickly configure, manage, and monitor the Aruba Instant On 1830 network switch.
Key Features
- 8 x Gigabit Ethernet Ports
- 4 x PoE+ Compliant Ethernet Ports
- 16 Gb/s Switching Capacity
- 11.90 Mpps Forwarding Rate
- 800MHz ARM Cortex-A9 CPU
- 512MB RAM
- Rackmount Design
- 65W Power Budget
- No Licensing Fees
- Mobile App & Cloud Management Support
Performance
The Aruba Instant On 1830 switch featuring an 800 MHz ARM Cortex-A9 processor with 512MB of memory, 215MB of flash storage, and a 1.5MB packet buffer. It's designed to deliver smooth data transfers with a 16 Gb/s switching capacity and 11.9 Mpps forwarding rate.
Easy Management
The Aruba Instant On mobile app allows you to remotely configure, monitor, and manage your network switch without needing any additional hardware such as cloud keys or a VPN. You can also update firmware on your Instant On devices directly from the cloud, no matter where you are or what time it is.
Power-over-Ethernet
This switch includes four PoE+ complaint ports with a 65W power budget. Features such as automatic power configuration and scheduling allow you to efficiently operate your connected devices.
Multi-Site Remote Management
The cloud-hosted web interface and mobile app make it easy to remotely manage multiple sites and multiple networks with distributed and multi-tenant deployments. Each site is logically separated and has its own configuration, statistics, guest portal, and admin read/write privileges. Instant On also allows you to create three admin accounts per site, offering the option to lock accounts from accidental deletion.
Link Aggregation
This switch supports up to 16 groups of eight network ports, which may be configured to form high-bandwidth connections to compatible devices.
Management
Cloud-Based Management
Use the cloud-hosted web interface and mobile app to manage your networks and devices from almost anywhere.
Local Web GUI Management
The built-in web-based interface makes it easy for non-technical users to directly manage the Instant On 1830 switch. The interface supports up to five HTTP and HTTPS sessions.
Simple Network Time Protocol
The Simple Network Time Protocol (SNTP) automatically synchronizes the switch's date and time for accurate system event tracking and various schedules set by the administrator.
Security
Trusted Platform Module
The integrated Trusted Platform Module (TPM) provides secure, hardware-based generation and storage for cryptographic keys that are used for connections to the Instant On cloud portal.
Automatic Denial-of-Service Protection
The Instant On 1830 manages high-volume traffic and prevents denial-of-service (DoS) attacks against the network.
Global Storm Control
Protects against conditions where incoming packets flood the LAN, causing network performance degradation for unicast traffic with an unknown destination, and for broadcast and multicast traffic.
Aruba Instant On 1830 Specs
Interfaces
| Ports | 8 x 10/100/1000 Mbps Gigabit Ethernet (RJ45) PoE |
Protocols
| Layer Services Supported | Layer 2 Support |
| Supported Protocols | Auto-MDIX/MDI IGMP Snooping Link Aggregation Port Mirroring |
| MAC Address Table Size | 8K |
Security
| Security Features | DoS Attack Prevention Storm Control |
Standards
| Supported IEEE Standards | 802.1d, 802.1p, 802.1q, 802.1w, 802.3, 802.3ab, 802.3ac, 802.3af, 802.3at, 802.3az, 802.3x, 802.3z |
Performance
| Latency | 2.8 to 5.2 µs |
| Forwarding Rate | 11.9 Mpps |
| Switching Bandwidth | 16 Gbps |
| Packet Buffer | 1.5 MB |
Computer
| Flash Memory | 256 MB |
| CPU | 800 MHz Cortex A9 Single-Core |
| Memory | 512 MB |
Electrical
| Power Draw | 86.07W (Max) 8.2W (Idle) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz at 0.5 to 1 A |
| PoE Power Budget | 65W |
| PoE per Port | 30W |
| Power Supply Type | Internal |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 15 to 95% |
| Storage Temperature | -40 to 158°F / -40 to 70°C |
| Storage Humidity | 15 to 95% |
| Operating Altitude | 10,000' / 3048 m |
General
| Cooling System | Passive |
| Mean Time Between Failures (MTBF) | 927,684 Hours |
| Rack Form Factor | 1 RU |
| Dimensions | 9.6 x 7.7 x 1.7" / 245.1 x 195.1 x 43.9 mm |
| Weight | 5.49 lbs / 2.49 kg |
Specifications:
| Specifications | Aruba Instant On 1830 8G Switch (JL810A) | Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch (JL811A) | Aruba Instant On 1830 24G 2SFP Switch (JL812A) | Aruba Instant On 1830 24G 12p Class4 PoE 2SFP 195W Switch (JL813A) | Aruba Instant On 1830 48G 4SFP Switch (JL814A) | Aruba Instant On 1830 48G 24p Class4 PoE 4SFP 370W Switch (JL815A) |
|---|---|---|---|---|---|---|
| Gigabit Copper Ports | 8; Class 3 PD (port 1) | 8; Class 4 (ports 1 -4) | 24 | 24; Class 4 (ports 1 -12) | 48 | 48; Class 4 (ports 1 -24) |
| Uplinks | — | — | 2 SFP 1GbE ports | 2 SFP 1GbE ports | 4 SFP 1GbE ports | 4 SFP 1GbE ports |
| Dimensions | 157.0(D) x 173.0(W) x 39.1(H) mm | 195.1(D) x 245.1(W) x 43.9(H) mm | 215.9(D) x 443.0(W) x 43.9(H) mm | 253.0(D) x 443.0(W) x 43.9(H) mm | 253.0(D) x 443.0(W) x 43.9(H) mm | 351.0(D) x 443.0(W) x 43.9(H) mm |
| Weight | 1.70 lb (0.77 kg) | 3.40 lbs (1.54 kg) | 5.50 lbs (2.49 kg) | 7.65 lbs (3.47 kg) | 7.80 lbs (3.54 kg) | 10.90 lbs (4.94 kg) |
| Throughput (Mpps) | 11.90 Mpps | 11.90 Mpps | 38.68 Mpps | 38.68 Mpps | 77.37 Mpps | 77.37 Mpps |
| Switching capacity | 16Gbps | 16Gbps | 52Gbps | 52Gbps | 104Gbps | 104Gbps |
| Reliability MTBF (years) | 188.2 | 105.9 | 203.6 | 96.6 | 114.4 | 83.5 |
| Maximum power rating | 100-127V: 8.09W 200-220V: 8.05W |
100-127V: 86.07W 200-220V: 83.67W |
100-127V: 19.1W 200-220V: 19W |
100-127V: 244.6W 200-220V: 237.2W |
100-127V: 40.2W 200-220V: 40W |
100-127V: 462.5W 200-220V: 452.5W |
| Warranty | Limited Lifetime Warranty | Limited Lifetime Warranty | Limited Lifetime Warranty | Limited Lifetime Warranty | Limited Lifetime Warranty | Limited Lifetime Warranty |
