Description
UHV-12X-IPS Professional grade USB 3.0, IP 3G-SDI & HDMI HD PTZ Video Camera is adopted Ambarella A9 ISP to output unparalleled image quality, applied for both cloud-base and on-premise video collaboration for cooperate, education, government. ..
Features
※ 3G-SDI & DVI-I simultaneously output※ Zoom: 12X optical Zoom +2X Digital Zoom※ Adopts most advanced DSP,1/2.8" inch 5MP sensor
※ 12x Optical Zoom + 2x digital zoom, with 72.5°field of view
※ 1080p60 video over IP, and support H.264, H.265 encoding
※ POE support: easy to use one RJ45 cable to get video, control and power supply
※ IP, HDMI, SDI, USB outputs, fit for different applications
※ Smooth PTZ mechanical design, accurate pan tilt motor control
※ Special focusing algorithm: fast and precise focusing performance when zooming or moving
※ WDR, 3D Noise Reduction feature
※ Standard IP Visca, Serial Visca, Pelco-P/D control protocol, IP Visca over TCP/UDP
※ Supplied with funcation IR remote controller, can set IP address via OSD menu
※ Automatic access to the IP address
※ 128 presets
※ Image flip function, support upside-down installation
※Support daisy chain feature
|
Model No. |
UHV-12X-IP-S |
||||
|
Camera |
|||||
|
Sensor |
1/2.8 inch, 5Mega Pixel High Quality CMOS sensor |
||||
|
Video System |
HDMI |
SDI |
IP |
USB3.0 |
USB2.0 |
|
1920X1080P60/50/30/25; |
1920x1080P60/50/30/25; |
Main Steam:1920x1080P60 |
1920x1080P60/50/30/25 |
1280x720P25,1024x576p30, |
|
|
Zoom |
12x optical zoom & 2x digital zoom |
||||
|
View Angle |
6.3°(wide) - 72.5°(tele) |
||||
|
Focal Length |
f=3.92(wide) - 47.32mm(tele) |
||||
|
Presets |
10 via remote controller: 128 via serial port; preset precision: 0.1° |
||||
|
Noise Reduction |
2D & 3D |
||||
|
SNR |
Above 50dB |
||||
|
Minimum Lux |
0.01Lux |
||||
|
White Balance |
Auto/Manual/Auto Tracking/One Push/Indoor/Outdoor |
||||
|
Anti Flicker |
50Hz/60Hz/OFF |
||||
